JYR4010 Plus End-fed Shortwave HF Antenna 4 Band 7/14/21/28MHz Joint Waterproof

Specification: Antenna Configuration: 2.5 mm² wire, 20 meters length, 20 meters guy rope, 1:64 balun Operating Bands: 10, 15, 20, 40-meter waves Power Handling: SSB < 150W, CW, FT8 < 100W Shipping Weight: 3.5 pounds Shipping Dimensions: 7.9*7.9*4 inches Due to the higher frequency of the 6-meter band, controlling the inductance of the magnetic ring can be challenging, so the antenna you purchase may have the opportunity to resonate on the 6-meter band (i.e., Band 5). It is advisable to select an open and elevated location. The balun has a radiator on one side and is empty on the other. This structure makes the antenna very convenient to set up; simply pull both ends with a rope, ensuring that the radiator and balun are more than 3 meters away from any objects. It can be horizontally, vertically, or diagonally pulled, and the balun can be placed either above or below, making it suitable for concealed setups, especially ideal for rapid deployment in urban areas and the wilderness. Wide Frequency Range: With support for multiple bands (40m, 20m, 15m, 10m), the half wave antenna provides exceptional performance across different frequencies, providing unparalleled flexibility for a wide range of radio applications Portable and Easy Installation: This end fed antenna is easy to install and carry due to its small size and lightweight design. Whether for long-term outdoor installations or temporary/moveable setups like field communication activities, its portable and foldable features simplify the process Durable Construction: Crafted with an ABS shell, the 1:64 Balun Antenna offers durability and excellent craftsmanship, ensuring longevity and reliability in various conditions Please ensure that the antenna is installed in a space of more than 45 meters, and try to place it in an open and unobstructed area at a high position to ensure excellent performance and effectiveness. When installing the antenna, the vertical inclination angle of the balun must not be greater than 20 degrees to ensure water resistance
